Valla
22E
The original Pick & Carry Crane
Max payload 2.250 kg
Total weight 1.970 kg
Dimensions 2.260 x 950 x 1.685 mm
Full electrical power unit
Zero impact
Technical data
FRONT N° 2 / 18 x 7 – 8”
REAR N° 1 / 300 x 135
HYDRAULICS 220 Bar – 4 kW AC
REAR-WHEEL DRIVE 1×3 kW AC
REAR STEERING 700 W AC – 180°
BATTERY 48V – 200 Ah
COUNTERWEIGHTS 270 kg
BRAKES Electro brakes
Optional
Winch
Manual Jib
Radio remote control
Automatic refill
On board battery charge
Carry deck
Front wheels electro brakes
Lithium batteries
ATEX transformation
Valla Connect System
