Valla
V180RC
Self-propelled crane with operator on board
Max payload 18.000 kg
Total weight 20.980 kg
Dimensions 4.540 x 2.000 x 1.980 mm
Full electrical power unit
Zero impact
Technical data
FRONT N° 4 S.E. 355/50 – 20”
REAR N° 2 S.E. 355/50 – 20”
HYDRAULICS 220 Bar – 33 kW AC
FRONT-WHEEL DRIVE 2×7.5 kW AC
REAR STEERING +/-90°
BATTERY 96V – 1.050 Ah
REMOVABLE COUNTERWEIGHTS N° 3 x 6.500 kg tot.
BRAKES Front electro-hydraulic
Optional
Winch
Front stabilizers
Not-foldable mechanic jib
Foldable hydraulic jib
Jib idraulico telescopico ripiegabile
Self-leveling forks
Lithium batteries
ATEX transformation
Valla Connect System
